*PLEASE CONTACT US PRIOR TO ORDERING TO CONFIRM STOCK AND ETA*
Garrett GT2260S PowerMax Turbocharger - VW MK7 & 7.5 Golf GTI & R.
*SUPPORTS UP TO 360KW*
*FITS ALL VW MK7 & 7.5 GOLF GTI, ED40, TCR & R MODELS*
The Garrett PowerMax™ turbocharger range is engineered to increase engine performance while maintaining OEM installation specifications.
The GT2260S can be directly bolted on as an upgrade with full stage 2 hardware.
More power can be made with aftermarket LPFP, HPFP and E85 as this is a journal bearing turbo with 17% more flow compared to stock IS38, maximising efficiency and air flow compared to the OEM turbocharger.
The Mar-M alloy turbine wheel and twin scroll stainless steel turbine housings are rated for up to 1050° C.
These turbochargers are fully assembled with a calibrated electronic actuator and ancillary components for direct OEM fitment.
Stage 1 Features:
• Direct-Fit
• 360kw rating
• 47mm compressor inducer, 60mm compressor exducer
• 50mm turbine inducer, 45mm turbine exducer
• 17% flow increase compared to IS38 turbo
• GTX Gen II compressor wheel aero
• Modern gasoline turbine wheel aerodynamics constructed of Mar-M alloy
• Stainless steel turbine housing rated for up to 1050C
• Fully machined speed sensor port
• Latest generation of journal bearing rotor group
• 360 degree thrust bearing, reinforced for application
*WARNING: Maximum allowable turbocharger speed is 185krpm*
The use of this product above max turbocharger speed is at the owner’s risk, and can result in damage and premature failure.
To protect the turbocharger from overspeed when operating, speed sensor ports are machined into the compressor housing. Sensor part numbers 781328-0003 (includes sensor and gauge), and 781328-0004 (includes speed sensor) are attainable via special order.
• AUDI TT 2.0 TFSI (EA888 Gen 3)
• Garrett PMAX Stages 1 and 2 upgrade turbos
• Larger intercooler
• Custom exhaust system
• Reinforced pistons - lowered compression ratio of 9.2:1
• Upgraded fuel system - larger high pressure fuel pump and larger injectors
• Transmission upgrades - software upgrade only
• Cylinder head upgrades - valve springs only
• Fuel - 98 octane unleaded (Stage 2 also run with ethanol mixture)
Included:
- Garrett GT2260S turbocharger
- Appropriate install hardware
